Place of Origin : Guangdong, China (Mainland)
Brand Name : AFK
Model Number : 2W-50K
Supply Ability : 5000 Piece/Pieces per Week
Packaging Details : pp box + export carton
MOQ : 10 - 49 Pieces
Price : Negotiable
Certification : CE
Application : General
Pressure : Low Pressure
Power : Solenoid
Medium : water, oil, gas
Body material : ss304/brass
Seal : NBR, EPDM, Viton
Warranty : 1 year
Type | Model NO. | Pipe size | Orfice Size |
2W-06K | 1/8" | 2.5mm | |
2W-08K | 1/4" | 4mm | |
2W-160-10K | 3/8" | 10m | |
2W-15K | 1/2" | 16mm | |
2W-20K | 3/4" | 20mm | |
2W-25K | 1" | 25mm | |
2W-32K | 1-1/4" | 32mm | |
2W-40K | 1-1/2" | 40mm | |
2W-50K | 2" | 50mm | |
Fluid | Air, Water, Oil, the neutral gas, Liquid | ||
Working Pressure | 1-10bar | ||
Service Voltage | AC110V/220V/DC24V/DC 12V (50/60Hz) , tolearance ±10% | ||
Operating | Pilot Type | ||
Type | Normally closed | ||
Body Material | Brass, stainless steel 304 | ||
| NBR | -5-80℃ | |
EPDM | -5-120℃ | ||
Viton | -5-150℃ |
1. What media is used for? water, oil, gas or others?
2. How much is working pressure?
3. What size do you need?
4. What is voltage?
5. What type do you need? normally closed or normally opened?
6. If you have special demands, pls advise media temperature and thread type.
![]() |
Pilot Operating Diaphragm Brass Normally Open 2 inch 12v Electric Water Valve Images |
