Low Pressure 1.5 inch Low Pressure 9v Irrigation Solenoid Valve with Timer

  • 1
  • 2

Place of Origin : Guangdong, China (Mainland)

Brand Name : AFK

Model Number : 150P

Supply Ability : 30000 Set/Sets per Week

Packaging Details : White box + Export packing

MOQ : 1 - 9 Sets

Price : Negotiable

Payment Terms : L/C, Western Union, MoneyGram

Temperature of Media : Medium Temperature

Power : Solenoid

Port Size : 1.5"

Structure : Pilot

Applicable medium : Water

orifice size : 40mm

Thread : G

Contact Now

Low Pressure 1.5 inch Low Pressure 9v Irrigation Solenoid Valve with Timer

One

Medium:Water

Temperature: Suitable water≤42℃, surroundings≤52℃

Application range: It is currently one of the most widely used electromagnetic valve in garden irrigation, large-scale garden lawn, stadium, farm, industrial dust and water treatment equipment.

Two

Model: 150P

Pressure: 0.1~1.04Mpa

connect size: 1.5"

Thread: G

Coil: AC220, AC110V, AC24V, 50/60HZ, 10VA

Orifice size: 40mm

Self-holding type coil: DC6-20V, Pulse Width (20-500mSec)

working model(+red&-black valve open)

(-red&-black valve closed)

Three

Material-body valve -nylon

enclosed-NBR

Moving iron core-430F

Static iron core-430F

Spring-SUS304

Sub-magnetic ring-Copper

Water treatment solenoid, normally closed, coil AC24V, Self-holding type coil DC6-20V (Please specify when ordering)

Product Description

Characteristic

1. The pilot type diaphragm structure , nylon body material.
2. Double filter to prevent clogging eletromagnetic core.
3. Fully enclosed eletromagnetic coil, waterproof.
4. A slow off function to prevent water harmmer, damage the system.
DESIGN FEATURES
1. Irrigation solenoid valve
2. Fit for stadium, farm, industrial dust and water treatment equipment.
3. Normally closed.
4.Pipe size : 1.5 "
5. Service voltage : DC Latching, AC110V, AC220V, AC24V, DC24V, DC12V, DC9V
6.Thread connnector :G
7.Material-body valve -nylon
Detailed Images
Low Pressure 1.5 inch Low Pressure 9v Irrigation Solenoid Valve with Timer
Low Pressure 1.5 inch Low Pressure 9v Irrigation Solenoid Valve with Timer
Product Show
Low Pressure 1.5 inch Low Pressure 9v Irrigation Solenoid Valve with Timer
